Modular design. Endless versatility.
Available in sizes ranging from 15 to 24 inches, including with and without stand options, you can easily configure the I‑Series to fit the needs of your business - from signage and point-of-sale to self-service, automation controls and more.
Universal VESA Mount
Conveniently mount the I‑Series with the built‑in VESA mount.
Expand with Edge Connect
Seamlessly attach a variety of peripherals to the edge of the touchscreen.
Reliable, security and performance.
Built with the reliability-tested performance and security of Intel 12th Generation processors, integrated Trusted Platform Modules, Intel vPro™ and the Windows 10 operating system, the I‑Series 3 delivers the dependability businesses need.
Support for Linux.
For added flexibility, the I‑Series 3 offers no OS models, all pretested with Linux SuSE, Ubuntu and Red Hat operating systems.
Bridge the gap between Windows and Android.
Transitioning to Android in the future? Elo Bridge is the perfect solution. Simply choose the Elo Windows device that fits your needs today, and when you are ready to transition to Android, you can use Elo Bridge to migrate your fleet of devices.
Elo Touch Solutions I-Series 3.0 Intel Core 5 i3-1215UL 38.1 cm (15") 1024 x 768 pixels Touchscreen All-in-One PC 8 GB DDR5-SDRAM 128 GB SSD Wi-Fi 6 (802.11ax) Black
SKU: E701155£1,461.62 ex VAT
£1,753.95 inc VAT
Out of stockDisplay Screen shape Flat HD type Not supported Display surface Anti-glare Panel type TFT Display diagonal 38.1 cm (15") Display resolution 1024 x 768 pixels LED backlight Yes Touchscreen Yes Touch technology Multi-touch Display brightness 400 cd/m² Viewing angle, vertical 150° Viewing angle, horizontal 160° 3D No Native aspect ratio 4:3 Response time 23 ms Processor Processor generation 12th gen Intel® Core™ i5 Processor cache type Smart Cache Processor frequency 1.2 GHz Processor boost frequency 4.4 GHz Processor family Intel Core 5 Processor model i3-1215UL Processor cores 6 Processor threads 8 Processor cache 10 MB Processor manufacturer Intel Processor base power 15 W Efficient-core Max Turbo Frequency 2.5 GHz Performance-core Max Turbo Frequency 4.4 GHz Performance cores 2 Efficient cores 4 Memory Internal memory 8 GB Memory layout (slots x size) 1 x 8 GB Maximum internal memory 32 GB Internal memory type DDR5-SDRAM Memory slots 2 Memory slots type SO-DIMM Memory clock speed 4800 MHz Hard drive Number of storage drives installed 1 Storage media SSD Total storage capacity 128 GB Storage Number of storage drives supported 1 Number of storage drives installed 1 Storage media SSD Total storage capacity 128 GB Optical drive type No SSD interface M.2 SSD capacity 128 GB Number of SSDs installed 1 SSD form factor M.2 Total SSDs capacity 128 GB NVMe Yes Graphics Discrete graphics card No On-board graphics card Yes Discrete graphics card model Not available On-board graphics card model Intel® UHD Graphics Audio Number of speakers 2 Built-in speaker(s) Yes RMS rated power 4 W Camera Built-in camera No Optical drive Optical drive type No Network Top Wi-Fi standard Wi-Fi 6 (802.11ax) Wi-Fi Yes Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) Ethernet LAN Yes Ethernet LAN data rates 10,100,1000 Mbit/s Bluetooth Yes Bluetooth version 5.3 Ports & interfaces USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4 USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity 1 USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 0 USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 0 Thunderbolt 3 ports quantity 0 Thunderbolt ports quantity 0 HDMI ports quantity 0 Headphone outputs 1 Ethernet LAN (RJ-45) ports 1 Technical details Power cord included Yes Product type All-in-One PC Product colour Black Wall mountable Yes Sustainability certificates ENERGY STAR Warranty period 33 year(s) Compliance certificates CB, CCC, Federal Communications Commission (FCC), Norma Oficial Mexicana (NOM), RCM, RoHS, State Radio Regulation of China (SRRC), UKCA, VCCI Security Trusted Platform Module (TPM) Yes Design Product colour Black Wall mountable Yes Panel mounting interface 75 x 75 mm VESA mounting Yes Performance Market positioning Business Product type All-in-One PC Trusted Platform Module (TPM) Yes Trusted Platform Module (TPM) version 2.0 Software Operating system installed No Power Power consumption (off) 0.5 W Autonomy mode No AC adapter power 180 W AC adapter frequency 50 - 60 Hz AC adapter input voltage 100 - 240 V AC adapter output voltage 24 V Power consumption (typical) 49 W Power consumption (standby) 5 W Multimedia Built-in camera No Pen Pen included No Weight & dimensions Package width 497 mm Package depth 487 mm Package height 345 mm Package weight 7.9 kg Width (with stand) 359.5 mm Depth (with stand) 197.5 mm Height (with stand) 356 mm Weight (with stand) 6.7 kg Packaging data Package width 497 mm Package depth 487 mm Package height 345 mm Package weight 7.9 kg Operational conditions Operating temperature (T-T) 0 - 40 °C Storage temperature (T-T) -20 - 50 °C Operating relative humidity (H-H) 20 - 80% Storage relative humidity (H-H) 5 - 95% Certificates Certification UL/cUL, FCC, IC, CE, CB Compliance certificates CB, CCC, Federal Communications Commission (FCC), Norma Oficial Mexicana (NOM), RCM, RoHS, State Radio Regulation of China (SRRC), UKCA, VCCI Sustainability Sustainability certificates ENERGY STAR Packaging content Power cord included Yes Quick start guide Yes Other features Autonomy mode No On-board graphics card Yes Viewing angle, vertical 150° Viewing angle, horizontal 160° SSD interface M.2 SSD capacity 128 GB Processor manufacturer Intel Power consumption (typical) 49 W Power consumption (standby) 5 W Number of SSDs installed 1 3D No Mean time between failures (MTBF) 50000 h Warranty period 33 year(s) Your parcel will arrive within 5 business days (excluding weekends and public holidays) after you place your order. Items are shipped in working days only, your order may arrive anytime between 7am and 9pm. Deliveries are not made on public holidays, so you can expect your order to arrive the next working day.
