Deliver power and data to your Power over Ethernet device using this mountable PoE+ midspan
This Gigabit Power over Ethernet (PoE+) injector supplies power and data connectivity to a Gigabit PoE-compliant device using standard Ethernet cable, at distances of up to 100 m (330 ft.).
The PoE midspan is a cost-effective alternative to upgrading your existing network switch to a PoE-capable model.
Convenience and cost savings
This versatile PoE injector lets you connect a PoE-powered device (PD) to a non-PoE network switch, so you can avoid the expense and aggravation of replacing your existing switch with a PoE-enabled model. It supplies up to 30 watts of power, so you can easily power and access a high-power PoE-compliant device, such as an IP camera or a wireless access point (WAP), using traditional copper (RJ45) Ethernet cable. The midspan injector makes it easy to extend data and power connectivity to your PoE+ device across long distances, even in a remote location where a typical power outlet isn’t available.
Easy to set up in mixed environments
You can integrate this compact injector discreetly into a variety of environments. It features a surface-mountable housing that’s perfect for installing on walls or under a desk, but it’s also palm-sized, for use on desktop surfaces.
Plus, with plug-and-play operation, you can enjoy fast and hassle-free setup without disrupting your workflow.
Intelligent power allocation
Not sure which class your PoE device is? The Gigabit PoE+ injector automatically detects the power requirements of your connected PoE PD, and delivers the appropriate level of power without damaging your device.
The POEINJ1GW is backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
StarTech.com 1-Port Gigabit Midspan - PoE+ Injector - 802.3at and 802.3af
SKU: POEINJ1GW£67.15 ex VAT
£80.58 inc VAT
In stockNetwork Networking standards IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u Duplex system Full Power over Ethernet (PoE) Yes Ethernet LAN data rates 10,100,1000 Mbit/s Ethernet interface type Gigabit Ethernet Cable types supported Cat5 Power over Ethernet (PoE) voltage 48 V Features Plug and Play Yes Maximum operating distance 100 m Product colour Black Networking standards IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u LED indicators Power Ports & interfaces DC-in jack Yes Ethernet LAN (RJ-45) ports 2 Power Output power 30 W Output current 0.64 A Power consumption (max) 36 W Power over Ethernet (PoE) voltage 48 V Input voltage 100 - 240 V Input current 0.75 A Technical details Package width 230 mm Package height 76 mm Power over Ethernet (PoE) Yes Input voltage 100 - 240 V Input current 0.75 A Ethernet LAN data rates 10,100,1000 Mbit/s Ethernet interface type Gigabit Ethernet Harmonized System (HS) code 85044095 Compliance certificates CE, RoHS Operational conditions Storage temperature (T-T) -20 - 85 °C Operating temperature (T-T) 0 - 45 °C Operating relative humidity (H-H) 10 - 90% Weight & dimensions Package weight 1 kg Package depth 190 mm Package width 230 mm Package height 76 mm Weight 50 g Width 63 mm Depth 70 mm Height 25 mm Packaging data Package weight 1 kg Package depth 190 mm Package width 230 mm Package height 76 mm Packaging content Power cord included Yes Quick installation guide Yes AC adapter included Yes Indication LED indicators Power Logistics data Master (outer) case width 400 mm Master (outer) case length 490 mm Master (outer) case height 260 mm Products per master (outer) case 12 pc(s) Harmonized System (HS) code 85044095 Your parcel will arrive within 5 business days (excluding weekends and public holidays) after you place your order. Items are shipped in working days only, your order may arrive anytime between 7am and 9pm. Deliveries are not made on public holidays, so you can expect your order to arrive the next working day.
