Share a mouse, keyboard, USB hub, and dual 4K 60Hz DisplayPort monitors, between two DisplayPort-enabled computers, featuring dual-view video matrix capabilities
The Video Matrix KVM Switch allows you to view one display from each connected computer and switch the keyboard, mouse, and audio device between the selected displays using hotkeys. You can also switch all connected peripherals and both monitors like a standard KVM.
Universal Compatibility
The TAA-Compliant KVM Switch provides BIOS/UEFI control and works with any operating system, including Windows, macOS, and Linux. No software is required, and it is compatible with all hardware platforms such as Intel, AMD, and Apple Silicon.
Customizable Switching
Switching KVM ports is easy with the front-facing push button, hotkeys, or the included remote selector cable. An audible buzzer provides confirmation, and LEDs offer quick visual port selection status.
Reliable Performance
The durable design features a steel housing that helps prevent Electro-Magnetic Interference (EMI), enhancing the stability and reliability of the KVM. Its sturdy construction makes it ideal for installation in a variety of environments, and it offers 8kV Air/6kV Contact ESD protection.
USB Audio
Eliminate the need to connect 3.5mm cables from the computers to the KVM by using this KVM switch's built-in USB audio device, which provides 3.5mm audio jacks for both microphone and speakers. This setup simplifies your workspace by integrating audio management directly into the KVM switch.
Enhance Productivity and Device Management with the StarTech.com Connectivity Tools Application
Developed to improve performance and security, StarTech.com Connectivity Tools is the only software suite on the market that works with a wide range of IT connectivity accessories. The software suite includes:
• Advanced Windows Layout Utility: Setup and save custom windows layouts.
• USB Event Monitoring Utility: Track and log connected USB devices.
For more information and to download the StarTech.com Connectivity Tools application, please visit: www.startech.com/connectivity-tools
The StarTech.com Advantage
StarTech.com 2-Port Dual-Monitor DisplayPort KVM Switch with Dual View Video Matrix, 4K 60Hz, 4x USB Hub Ports, Hotkey Switching, DP 1.2 Matrix KVM, TAA Compliant
SKU: P2ADD121D-KVM-SWITCH£292.02 ex VAT
£350.42 inc VAT
In stockPorts & interfaces Console USB ports quantity 4 Console ports 3.5mm headphone, 3.5mm mic, DisplayPort, USB A Number of microphone inputs 1 DisplayPorts quantity 4 DisplayPort version 1.2 Number of computers controlled 2 Keyboard port type USB Mouse port type USB Video port type DisplayPort Audio connections Yes Headphone outputs 1 DC-in jack Yes USB hub Yes USB 2.0 Type-B ports quantity 2 USB 2.0 Type-A hub ports quantity 2 Console DisplayPorts ports quantity 2 Performance Daisy chain No Data transfer rate (max) 0.48 Gbit/s HD type 4K Ultra HD Maximum resolution 3840 x 2160 pixels Scan interval 10,20,30,40,50,60 s Audio channels 2.0 Technical details Product colour Black Rack mounting No Scan interval 10,20,30,40,50,60 s Push button Yes On Screen Display (OSD) No LED indicators Yes Hot keys Yes IP control No USB hub Yes Compliance certificates Federal Communications Commission (FCC), RoHS, Trade Agreements Act (TAA) Design Wired remote switch Yes Mean time between failures (MTBF) 87298 h Product colour Black Rack mounting No Push button Yes LED indicators Yes Hot keys Yes Housing material Aluminium, Steel Display Built-in display No On Screen Display (OSD) No Power Input current 1 A Output current 3 A Power plug type Type M Compatible power plug types AU, EU, UK, US Output voltage 12 V Power source DC Power consumption (typical) 36 W Input voltage 100 - 240 V Video HD type 4K Ultra HD Maximum resolution 3840 x 2160 pixels Sustainability Compliance certificates Federal Communications Commission (FCC), RoHS, Trade Agreements Act (TAA) Operational conditions Operating temperature (T-T) 0 - 40 °C Storage temperature (T-T) -20 - 60 °C Operating relative humidity (H-H) 0 - 90% Weight & dimensions Width 105 mm Depth 221 mm Height 26 mm Weight 626 g Package width 250 mm Package depth 292 mm Package height 78 mm Package weight 1.5 kg Packaging data Package width 250 mm Package depth 292 mm Package height 78 mm Package weight 1.5 kg Packaging content Quick installation guide Yes AC adapter included Yes Other features IP control No Push button Yes Hot keys Yes Logistics data Master (outer) case width 539 mm Master (outer) case length 419 mm Master (outer) case height 333 mm Products per master (outer) case 10 pc(s) Your parcel will arrive within 5 business days (excluding weekends and public holidays) after you place your order. Items are shipped in working days only, your order may arrive anytime between 7am and 9pm. Deliveries are not made on public holidays, so you can expect your order to arrive the next working day.
