Control two computers from a single console, with high-resolution DisplayPort video, USB keyboard, mouse, and audio
The SV231DPUA 2-Port USB DisplayPort KVM Switch delivers dual computer KVM control, for demanding high definition multimedia applications. Supporting DisplayPort connections with a native resolution of 2560 x 1600, and support for both 7.1 HD digital audio (when connected to supporting displays and sources) and 3.5mm stereo analog audio/mic.
A simple, yet comprehensive KVM solution, the 2-port switch features both front-panel push-buttons and hotkey switching, and offers a small form factor design with connection ports situated on the rear panel. A Plug-and-Play USB 2.0 hub port allows you to share an additional USB peripheral between the 2 connected computers, avoiding the expense of purchasing duplicate peripheral devices.
A suitable solution for medical applications (MRI, X-ray diagnostics etc.), the KVM switch supports a maximum resolution of 3840 x 2400 at a reduced refresh rate.
Backed by a StarTech.com 3-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Compatible with Mini-DisplayPort adapters, making it suitable for Apple MacBook connectivity
- Support for both analog and digital audio sources provides the versatility to use either connection depending on preference/availability
- USB peripheral sharing eliminates the expense of duplicate devices (printers, scanners, etc.)
StarTech.com 2 Port Professional USB DisplayPort KVM Switch with Audio
SKU: SV231DPUA£188.99 ex VAT
£226.79 inc VAT
In stockPorts & interfaces Console USB ports quantity 4 Console ports 3.5mm headphone, 3.5mm mic, DisplayPort, USB A USB connector type USB Type-A Number of microphone inputs 3 DisplayPorts quantity 2 Number of computers controlled 2 Keyboard port type USB Mouse port type USB Video port type DisplayPort Audio connections Yes Headphone outputs 3 DC-in jack Yes USB hub Yes Network Ethernet LAN No Performance DDC2B support Yes Daisy chain No HD type 4K Ultra HD Hot-Plug support Yes Plug and Play Yes Maximum resolution 3840 x 2400 pixels Audio channels 7.1 Technical details Product colour Black Rack mounting No Hot-Plug support Yes Plug and Play Yes Push button Yes On Screen Display (OSD) No LED indicators Yes Hot keys Yes IP control No Audio support No USB hub Yes Compliance certificates RoHS Design Product colour Black Rack mounting No Push button Yes LED indicators Yes Hot keys Yes Certification CE, UL, FCC, REACH Housing material Steel Display Built-in display No On Screen Display (OSD) No Power Input current 0.8 A Output current 2 A Power plug type Type M Compatible power plug types AU, EU, UK, US Output voltage 12 V Power consumption (typical) 24 W External power adapter Yes Input voltage 110 - 240 V Video HD type 4K Ultra HD Maximum resolution 3840 x 2400 pixels Sustainability Compliance certificates RoHS Operational conditions Operating temperature (T-T) 0 - 40 °C Storage temperature (T-T) -20 - 60 °C Operating relative humidity (H-H) 0 - 80% Weight & dimensions Width 220 mm Depth 130 mm Height 44 mm Weight 1.1 kg Package width 100 mm Package depth 250 mm Package height 181 mm Package weight 1.3 kg Packaging data Package width 100 mm Package depth 250 mm Package height 181 mm Package weight 1.3 kg Packaging content Rubber feet Yes Manual Yes AC adapter included Yes Certificates Certification CE, UL, FCC, REACH Other features IP control No Audio support No Push button Yes Hot keys Yes Logistics data Harmonized System (HS) code 85176200 Your parcel will arrive within 5 business days (excluding weekends and public holidays) after you place your order. Items are shipped in working days only, your order may arrive anytime between 7am and 9pm. Deliveries are not made on public holidays, so you can expect your order to arrive the next working day.
