Easily connect and hot swap up to three 3.5” SATA/SAS hard drives from two 5.25” bays
The HSB3SATSASBA Removable 3-drive backplane lets you quickly install and hot-swap 3.5" drives from the front of your computer, by turning two 5.25" bays into a hot-swappable interface for you to connect up to three 3.5” SATA or SAS hard drives (HDD).
For added versatility, the hard drive bay can interface with SATA I/II/III and SAS I/II hard drives -- an ideal accommodation for enterprise system applications.
For a quick and secure method of installing and removing drives, the backplane features ejection levers and a key-lock design. To help prevent drive failure, the bay provides excellent heat dissipation with a built-in fan, and a vented solid aluminum enclosure.
The HSB3SATSASBA is backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
StarTech.com 3 Bay Aluminum Trayless Hot Swap Mobile Rack Backplane for 3.5in SAS II/SATA III - 6 Gbps HDD
SKU: HSB3SATSASBA£63.87 ex VAT
£76.65 inc VAT
In stockStorage Hot-swap drive bays Yes Installed storage drive type No Supported storage drive types HDD Number of storage drives supported 3 Storage drive interface Serial ATA, Serial ATA II, Serial ATA III Storage drive size 3.5" Storage drives installed No Maximum supported storage capacity 12 TB Data transfer rate 6 Gbit/s Ports & interfaces Number of SATA power connectors 2 SATA power connector type SATA 15-pin SATA host port Yes Host ports 3 Technical details Backplanes support Yes Number of fans 1 fan(s) Product colour Black Internal No LED indicators Activity, Power Data transfer rate 6 Gbit/s Harmonized System (HS) code 84717020 Compliance certificates RoHS Design Number of fans 1 fan(s) Product colour Black Internal No LED indicators Activity, Power Performance Backplanes support Yes Weight & dimensions Width 145 mm Depth 194.1 mm Weight 1.2 kg Height 110 mm Package width 179 mm Package depth 253 mm Package height 123 mm Package weight 1.2 kg Packaging data Package width 179 mm Package depth 253 mm Package height 123 mm Package weight 1.2 kg Cables included SATA Packaging content Cables included SATA Operational conditions Storage temperature (T-T) -20 - 60 °C Operating temperature (T-T) 0 - 55 °C Operating relative humidity (H-H) 5 - 85% Other features Compliance certificates RoHS Logistics data Products per master (outer) case 8 pc(s) Master (outer) case width 386 mm Master (outer) case length 523 mm Master (outer) case height 290 mm Harmonized System (HS) code 84717020 Your parcel will arrive within 5 business days (excluding weekends and public holidays) after you place your order. Items are shipped in working days only, your order may arrive anytime between 7am and 9pm. Deliveries are not made on public holidays, so you can expect your order to arrive the next working day.
