Install four SATA drives via one M.2 slot for a high-density storage solution
Add up to four independent SATA drives to a desktop via a single 2280 M.2 drive slot, maintaining SATA 6Gbps read/write speeds per drive.
Cost-Effective Storage Expansion
This setup can be used with modern motherboards or external enclosures that feature a PCIe-based M.2 slot, allowing for a cost-effective expansion of storage capabilities. Four 19.6-inch (50cm) SATA cables are included to connect the HDDs or SSDs for quick installation.
Compatibility
The drivers auto-install in most major operating systems, including Windows 8 and later, macOS, and Linux. This adapter card is compatible with all hardware platforms, such as Intel and AMD, and supports software storage management, including Microsoft's Storage Spaces.
Applications
This storage expansion card is ideal for data storage, backups, NAS setups, photographers, videographers, and content creation, where large storage capacity and reliability is required.
ASMedia ASM1064 Chipset
The 4-Port M.2 NVMe to SATA Adapter supports TRIM, SMART data pass-through, SATA I/II/III, and PCI Express 3.0.
Note: Only compatible with PCIe-based B-key or M-key M.2 drive slots
Note: Not compatible with SATA-based M.2 drive slots
The StarTech.com Advantage
StarTech.com 4-Port M.2 to SATA Adapter Card, M.2 PCIe 3.0 to SATA HDD/SSD Expansion Card, ASM1064 Chipset, M.2 NVMe to 4x HDD/SSD for Windows/macOS/Linux
SKU: 4P-SATA-M2-ADAPTER£26.98 ex VAT
£32.37 inc VAT
In stockPorts & interfaces Internal Yes Port multiplier Yes Output interface SATA Internal SATA ports quantity 4 Host interface M.2 Expansion card standard PCI 3.0 Technical details Chipset ASMedia ASM1064 Compliance certificates RoHS Performance Port multiplier Yes Hot-swap Yes Chipset ASMedia ASM1064 Product colour Green TRIM support Yes S.M.A.R.T. support Yes Colour Product colour Green Design Mean time between failures (MTBF) 68555579 h Hot-swap Yes Internal Yes Product colour Green LED indicators Power Features Chipset ASMedia ASM1064 TRIM support Yes S.M.A.R.T. support Yes Operational conditions Operating temperature (T-T) 0 - 70 °C Storage temperature (T-T) -20 - 80 °C Operating relative humidity (H-H) 20 - 80% System requirements Windows operating systems supported Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64 Mac operating systems supported Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma Linux operating systems supported Yes Weight & dimensions Width 22 mm Depth 80 mm Height 11 mm Weight 8 g Package width 142 mm Package depth 170 mm Package height 30 mm Package weight 142 g Packaging data Package width 142 mm Package depth 170 mm Package height 30 mm Package weight 142 g Cables included SATA User guide Yes Packaging content Cables included SATA User guide Yes Other features Chipset ASMedia ASM1064 Your parcel will arrive within 5 business days (excluding weekends and public holidays) after you place your order. Items are shipped in working days only, your order may arrive anytime between 7am and 9pm. Deliveries are not made on public holidays, so you can expect your order to arrive the next working day.
