StarTech.com 4-Port PCIe Gigabit Network Adapter Card

SKU: ST1000SPEX43
£119.75 ex VAT
£143.70 inc VAT
Product in stockIn stock
  • Add four Gigabit Ethernet ports to a client, server or workstation through one PCI Express slot

    Now you can add four separate Gigabit network ports to your client, server or workstation through just one PCI Express slot, to provide connectivity to multiple networks without draining your budget.

    Reliable connectivity to multiple networks

    This 4-port network card delivers powerful connectivity for your business, corporate or government office environment, with support for high-performance, 4-channel networking and a maximum throughput of up to 1000Mbps in each direction (2000 Mbps total). The network adapter card features the Realtek RTL8111G chipset, which is designed to deliver the performance and enhanced capabilities you need for reliable network connections to your server or computer.

    A versatile and cost-effective solution

    This versatile quad-port network card is ideal for many business applications requiring upgrades to servers or workstations, adding feature-rich Gigabit networking with four independent ports. Compatible with a broad range of operating systems, this cost-effective PCIe Gigabit NIC is suitable for many SMB and Enterprise applications such as virtualized environments that require multiple NICs (check your VM software for chipset compatibility).

    The ST1000SPEX43 is backed by a StarTech.com 2-year hardware warranty and free lifetime technical support.

    The StarTech.com Advantage

    - Add four independent Gigabit RJ45 ports to connect to multiple networks for high-bandwidth workstations and servers
    - Realtek RTL8111G chipset for reliable performance
    - Supports full-duplex flow control
  • Ports & interfaces
    InternalYes
    Ethernet LAN (RJ-45) ports4
    InterfaceEthernet
    Host interfacePCI Express
    Connectivity technologyWired
    Bandwidth
    Full duplexYes
    Maximum data transfer rate2000 Mbit/s
    Network
    ChipsetRealtek RTL8111G
    Ethernet LANYes
    Cabling technology10/100/1000BaseT(X)
    Networking standardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab
    Wake-on-LAN readyYes
    Auto MDIX IEEENo
    Jumbo frames supportYes
    Full duplexYes
    Ethernet LAN data rates10,1000,100 Mbit/s
    Maximum data transfer rate2000 Mbit/s
    Flow control supportYes
    Technical details
    Wake-on-LAN readyYes
    Auto MDIX IEEENo
    Harmonized System (HS) code85176990
    Compliance certificatesCE, RoHS
    Case colourYellow
    Design
    ChipsetRealtek RTL8111G
    InternalYes
    LED indicatorsActivity, Link
    Software
    Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
    Linux operating systems supportedYes
    Indication
    LED indicatorsActivity, Link
    System requirements
    Server operating systems supportedWindows Server 2003, Windows Server 2012, Windows Server 2016, Windows Server 2019
    Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
    Linux operating systems supportedYes
    Operational conditions
    Operating temperature (T-T)0 - 55 °C
    Storage temperature (T-T)-40 - 75 °C
    Operating relative humidity (H-H)5 - 95%
    Weight & dimensions
    Width120 mm
    Depth138 mm
    Height18 mm
    Weight95 g
    Package width209 mm
    Package depth145 mm
    Package height40 mm
    Package weight184 g
    Packaging data
    Package width209 mm
    Package depth145 mm
    Package height40 mm
    Package weight184 g
    Performance
    Server operating systems supportedWindows Server 2003, Windows Server 2012, Windows Server 2016, Windows Server 2019
    Wake-on-LAN readyYes
    Auto MDIX IEEENo
    Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
    Linux operating systems supportedYes
    Other features
    ChipsetRealtek RTL8111G
    Case colourYellow
    Flow control supportYes
    Harmonized System (HS) code85176990
    Logistics data
    Master (outer) case width446 mm
    Master (outer) case length521 mm
    Master (outer) case height344 mm
    Products per master (outer) case50 pc(s)
    Harmonized System (HS) code85176990
