USB 3.2 Gen 2 (10 Gbps) | PCI-Express 3.0 | PCIe x4 Slot | USB Type-A
This PCIe USB 3.2 Gen 2 controller card installs into an available PCI-Express x4 slot in your computer and enables you to upgrade your current system by adding four SuperSpeed USB-A (10Gbps) ports. The card features dual ASM3142 controllers with up to 20 Gbps of total bandwidth shared across all 4 ports.
Add Four 10 Gbps USB Type-A Ports to Your Desktop Computer
The controller card enables you to connect four USB-A Gen 2 (10 Gbps) devices to your desktop computer. The USB-A ports are ideal for connecting USB devices such as external hard drives and solid state drives or powering and syncing your mobile devices. The USB-A ports provides up to 4.5W (5V/0.9A) of power per USB port, and are backward compatible with USB 3.2 Gen 1 (5 Gbps), and USB 2.0 (480 Mbsp) devices.
Note: USB 3.2 Gen 2 (10 Gbps) is also know as USB 3.1 Gen 2 (10 Gbps), and USB 3.2 Gen 1 (5 Gbps) is also know as USB 3.1 Gen 1 and USB 3.0 (5 Gbps).
SuperSpeed USB 3.2 Gen 2 (10 Gbps) Performance
The USB 3.2 Gen 2 card features dual ASMedia ASM3142 host controllers that utilizes x4 lanes of the PCIe 2.0 bus, making the card capable of speeds up to 10 Gbps on each port, and enabling fast access to high-performance devices like NVMe drives and SSDs. The controller cards support Multiple INs to reduce bandwidth loss when multiple devices are connected, even when connected through a USB Hub (Note: The USB hub must also support this feature). The card also supports UASP for improved performance with storage devices.
Wide Installation Compatibility
This add-on card includes a full-profile installation bracket ensuring you can install it into full-profile PCIe 2.0 x4 slots. For wide platform support the card is compatible with Windows, Linux and macOS. For hassle-free installation the drivers install automatically on computers running Windows 8 or higher. Works w/USB 3.2/3.0/2.0 devices
PEXUSB314A2V2 is backed by a StarTech.com lifetime warranty and free 24/5 multi-lingual North American based technical support. StarTech.com has been the IT professionals' choice for over 30 years.
The StarTech.com Advantage
StarTech.com 4-Port USB PCIe Card - 10Gbps USB 3.1/3.2 Gen 2 Type-A PCI Express Expansion Card with 2 Controllers - 4x USB-A - USB PCIe Add-On Adapter Card - Windows/Mac/Linux
SKU: PEXUSB314A2V2£85.08 ex VAT
£102.09 inc VAT
In stockPorts & interfaces Internal Yes USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4 Output interface USB 3.2 Gen 2 (3.1 Gen 2) Internal SATA ports quantity 1 Host interface PCIe Expansion card standard PCIe 3.0 SATA power connector type SATA 15-pin Technical details Chipset ASMedia - ASM3142, ASMedia - ASM1812 Data transfer rate (max) 10 Gbit/s Sustainability compliance Yes Compliance certificates CE, RoHS Performance UASP support Yes Chipset ASMedia - ASM3142, ASMedia - ASM1812 Data transfer rate (max) 10 Gbit/s Product colour Black, Metallic Harmonized System (HS) code 84733020 Colour Product colour Black, Metallic Design Mean time between failures (MTBF) 40000 h Internal Yes Product colour Black, Metallic Features UASP support Yes Chipset ASMedia - ASM3142, ASMedia - ASM1812 Data transfer rate (max) 10 Gbit/s Harmonized System (HS) code 84733020 Power Output voltage 5 V Operational conditions Operating temperature (T-T) 5 - 50 °C Storage temperature (T-T) -20 - 60 °C Operating relative humidity (H-H) 20 - 80% System requirements Windows operating systems supported Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64 Mac operating systems supported Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura Linux operating systems supported Yes Server operating systems supported Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 Weight & dimensions Width 150 mm Depth 120 mm Height 19 mm Weight 125 g Package width 207 mm Package depth 144 mm Package height 38 mm Package weight 180 g Packaging data Mounting brackets included Yes Package width 207 mm Package depth 144 mm Package height 38 mm Package weight 180 g Quick installation guide Yes Logistics data Products per master (outer) case 20 pc(s) Master (outer) case width 440 mm Master (outer) case length 420 mm Master (outer) case height 320 mm Harmonized System (HS) code 84733020 Packaging content Mounting brackets included Yes Quick installation guide Yes Other features Chipset ASMedia - ASM3142, ASMedia - ASM1812 Your parcel will arrive within 5 business days (excluding weekends and public holidays) after you place your order. Items are shipped in working days only, your order may arrive anytime between 7am and 9pm. Deliveries are not made on public holidays, so you can expect your order to arrive the next working day.
