Add 8 DIN Rail-mountable RS232 Serial ports to any system through USB
The ICUSB2328I Industrial 8-Port USB to Serial Hub with DIN Rail Clips converts a single USB port into eight RS232 serial ports, enabling you to connect to, monitor and control your serial devices.
Featuring rugged metal construction, with sturdy wall-mounting brackets and top-hat DIN Rail clips (included), this 8 port USB to RS232 Serial Hub provides versatile mounting options and a robust solution for both harsh industrial environments and simple desktop installations.
This USB powered adapter also retains assigned serial COM port values once connected, allowing the same values to be automatically reassigned to the USB serial hub ports.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
StarTech.com 8 Port USB to DB9 RS232 Serial Adapter Hub – Industrial DIN Rail and Wall Mountable
SKU: ICUSB2328I£143.95 ex VAT
£172.73 inc VAT
In stockPorts & interfaces Host interface USB 2.0 Type-B RS-232 ports 8 Hub interfaces Serial Card reader integrated No Ports quantity 8 Features LED indicators Activity Product colour Black Housing material Steel Host interface USB 2.0 Type-B Power Input current 0.25 A Power plug type Type M USB powered Yes Input voltage 5 V Technical details Product colour Black Sustainability compliance Yes Compliance certificates CE, RoHS Performance Card reader integrated No Data bits 7, 8 Stop bits 1, 2 FIFO (First In, First Out) 4048 B Baud rate 921.6 Kbit/s Mean time between failures (MTBF) 146300 h Parity bit Even, Mark, No, Odd, Space Harmonized System (HS) code 84719000 System requirements Windows operating systems supported Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 2000, Windows 2000 Professional, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 98SE, Windows CE, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 Mac operating systems supported Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura Linux operating systems supported Yes Other operating systems supported Windows XP Embedded Server operating systems supported Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016 Storage Card reader integrated No Weight & dimensions Weight 544 g Width 100 mm Depth 180 mm Height 43.2 mm Package width 296 mm Package depth 191 mm Package height 71 mm Package weight 862 g Packaging data Package width 296 mm Package depth 191 mm Package height 71 mm Package weight 862 g Packaging content Manual Yes Cables included USB Drivers included Yes DIN rail kit included Yes Design LED indicators Activity Product colour Black Operational conditions Operating temperature (T-T) 0 - 55 °C Storage temperature (T-T) -20 - 85 °C Operating relative humidity (H-H) 5 - 95% Indication LED indicators Activity Sustainability Sustainability compliance Yes Logistics data Master (outer) case width 405 mm Master (outer) case length 510 mm Master (outer) case height 320 mm Products per master (outer) case 14 pc(s) Harmonized System (HS) code 84719000 Other features Chipset FTDI - FT232RL Your parcel will arrive within 5 business days (excluding weekends and public holidays) after you place your order. Items are shipped in working days only, your order may arrive anytime between 7am and 9pm. Deliveries are not made on public holidays, so you can expect your order to arrive the next working day.
