Convert a single USB port into eight serial ports, and connect multiple hubs together for a scalable solution
This 8-port USB-to-serial adapter hub provides an easy and cost-efficient way to add RS232 serial capability to your industrial setting. It features a sturdy, rack-mountable chassis, and supports daisy chaining, so you can connect multiple hubs together to increase your serial device port count.
A scalable solution for changing needs
This rack-mountable USB serial hub (FTDI) lets you add eight serial ports (RS232), with full control from your desktop or laptop computer system using a single USB port. The daisy-chain function gives you a cost-effective and scalable way to increase your serial port count and expand as your needs grow, without investing in a more expensive serial hub.
Providing full control of your serial components from a single device, the USB serial hub is ideal for a multitude of applications including industrial automation, self-serve automated kiosks, and monitoring of cameras and security systems.
Built-in convenience
The hub features COM port retention, which retains the assigned serial COM port values. This ensures that the same values are automatically re-assigned to the port provided by the adapter, in the event it is disconnected and re-connected to the host computer.
The hub features a reliable FTDI USB-to-serial chipset, which provides easy installation into a broad range of operating systems.
Meets the demands of industrial environments
With its all-metal chassis, this rugged, rack-mountable hub fits into standard 19-inch server storage racks to provide an efficient industrial serial solution. It supports an extended operating temperature range of -40°C to 85°C (-40°F to 185°F), ensuring reliable performance even in the harshest environments. The USB-serial hub includes both an AC adapter and terminal block power, providing versatile power options.
The ICUSB23208FD is backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
StarTech.com 8-Port USB-to-Serial Adapter Hub
SKU: ICUSB23208FD£218.65 ex VAT
£262.38 inc VAT
In stockPorts & interfaces Host interface USB 2.0 Terminal block port Yes RS-232 ports 8 Hub interfaces Serial USB 2.0 ports quantity 1 DC-in jack Yes Ports quantity 8 Features LED indicators Yes Product colour Black Housing material Aluminium Host interface USB 2.0 Power Power consumption (max) 36 W Input current 1.5 A Power plug type Type B Output voltage 12 V Output current 3 A Input voltage 100 - 240 V Technical details Product colour Black Compliance certificates CE, RoHS System requirements Windows operating systems supported Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 2000, Windows 2000 Professional, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows CE, Windows Vista, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows Vista x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 Mac operating systems supported Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura Linux operating systems supported Yes Other operating systems supported Windows XP Embedded Server operating systems supported Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2 Weight & dimensions Weight 1.36 kg Width 120 mm Depth 430 mm Height 45 mm Package width 449 mm Package depth 217 mm Package height 64 mm Package weight 2.1 kg Packaging data Package width 449 mm Package depth 217 mm Package height 64 mm Package weight 2.1 kg Packaging content Terminal block included Yes Quick installation guide Yes Included power plug types AU, EU, NA, UK Cables included USB Drivers included Yes DIN rail kit included Yes Design LED indicators Yes Product colour Black Operational conditions Operating temperature (T-T) -40 - 85 °C Storage temperature (T-T) -65 - 150 °C Operating relative humidity (H-H) 20 - 80% Indication LED indicators Yes Performance Data bits 7, 8 Stop bits 1, 2 FIFO (First In, First Out) 256 B Baud rate 921.6 Kbit/s Mean time between failures (MTBF) 67114 h Parity bit Even, Mark, No, Odd, Space Harmonized System (HS) code 84719000 Logistics data Master (outer) case width 472 mm Master (outer) case length 344 mm Master (outer) case height 236 mm Products per master (outer) case 5 pc(s) Harmonized System (HS) code 84719000 Other features Chipset FTDI - FT4232 Your parcel will arrive within 5 business days (excluding weekends and public holidays) after you place your order. Items are shipped in working days only, your order may arrive anytime between 7am and 9pm. Deliveries are not made on public holidays, so you can expect your order to arrive the next working day.
