Vastly increase system performance by adding a dual mSATA SSD RAID array into any 2.5" SATA HDD application with the 25SAT22MSAT mSATA to SATA adapter.
Utilize the full potential of your SATA III controller, with mSATA SSDs reducing your data transfer bottleneck with file transfer speeds up to 6 Gbps. mSATA SSDs also save you money by reducing your power consumption over regular platter drives.
You can achieve greater SSD capacity, or data redundancy with the Dual SSD controller supporting multiple RAID modes (RAID 0, 1, BIG). The SSD adapter also supports non-RAID operation (JBOD) when paired with a port-multiplying SATA controller, so both drives can be used independent of one another.
Help protect the health of your drive with an open-frame design ensuring maximum heat dissipation.
The 25SAT22MSAT is backed by a StarTech.com 2-year warranty, and lifetime technical support.
The StarTech.com Advantage
- Maximize system speed by adding SSD performance
- Achieve greater drive capacity, or secure data redundancy with multiple RAID modes
- Reduce overall power consumption, with high efficiency mSATA SSDs
StarTech.com Dual mSATA SSD to 2.5” SATA RAID Adapter Converter
SKU: 25SAT22MSAT£13.04 ex VAT
£15.65 inc VAT
In stockPorts & interfaces Internal Yes Port multiplier Yes Output interface mSATA SATA revision 3.0 Host interface SATA Technical details Plug and Play Yes Chipset JMicron JMS562 RAID levels 0, 1, BIG, JBOD Data transfer rate (max) 6 Gbit/s Compliance certificates RoHS Performance Port multiplier Yes Hot-swap No Plug and Play Yes Chipset JMicron JMS562 RAID levels 0, 1, BIG, JBOD Data transfer rate (max) 6 Gbit/s Product colour Black, Green Harmonized System (HS) code 84733020 Certificates Certification CE, FCC Colour Product colour Black, Green Design Mean time between failures (MTBF) 5101299 h Hot-swap No Internal Yes Product colour Black, Green Certification CE, FCC Features Plug and Play Yes Chipset JMicron JMS562 RAID levels 0, 1, BIG, JBOD Data transfer rate (max) 6 Gbit/s Harmonized System (HS) code 84733020 Operational conditions Operating temperature (T-T) -40 - 85 °C System requirements Windows operating systems supported Yes Mac operating systems supported Yes Linux operating systems supported Yes Weight & dimensions Width 70 mm Depth 97 mm Height 7 mm Weight 39 g Package width 174 mm Package depth 145 mm Package height 32 mm Package weight 107 g Packaging data Mounting brackets included Yes Package width 174 mm Package depth 145 mm Package height 32 mm Package weight 107 g Quick installation guide Yes Logistics data Harmonized System (HS) code 84733020 Packaging content Mounting brackets included Yes Quick installation guide Yes Other features Chipset JMicron JMS562 Your parcel will arrive within 5 business days (excluding weekends and public holidays) after you place your order. Items are shipped in working days only, your order may arrive anytime between 7am and 9pm. Deliveries are not made on public holidays, so you can expect your order to arrive the next working day.
