USB Type-C Docking Station| Triple 4K with DP 1.4 & HDMI 2.0 | 100W PD | 6x Downstream USB Ports
This USB-C Gen 2 10Gbps docking station turns your USB-C ® or Thunderbolt™ 3 Windows laptop or Chromebook into a powerful workstation. A USB 3.2 Gen 2 Type-C dock features everything you need, from triple video outputs up to 4K 60Hz to 10Gbps USB-C & USB-A downstream peripheral ports to 100W Power Delivery.
HDMI & DisplayPort for Multiple Monitor Outputs
This USB-C Gen 2 docking station with DP 1.4 and HDMI 2.0 HBR3 support, is a perfect choice for dual or triple monitor setup, supporting up to triple 4K 30Hz nearly uncompressed video resolution output , with two DisplayPort and one HDMI outputs. Maximum dual and triple 4K display performance is supported on USB-C 11th Gen Intel-based (DP 1.4 HBR3 with DSC support) Windows Thunderbolt 3 or USB-C laptops, but backwards compatibility to older laptop generations and lower resolution monitor requirements.
DP 1.4 HBR3 with DSC Enabled
DP 1.4 HBR3 (without DSC)
DP 1.2 HBR2
Triple Display
Up to 4096 x 2160 @ 30Hz
Up to 1920 x 1080 @ 60Hz
Up to 1600 x 900 @ 60Hz
Dual Display
Up to 4096 x 2160 @ 60Hz*
*HDMI port + DP port or 2 DP ports
Up to 2560 x 1440 @ 60Hz
Up to 1920 x 1080 @ 60Hz
Single Display
Up to 4096 x 2160 @ 60Hz
Up to 3840 x 2160 @ 60Hz
Up to 3840 x 2160 @ 30Hz
Power & Charge with 100W Power Delivery
Power and charge USB-C/Thunderbolt 3 workstation laptops & ultrabooks with 100 watt power delivery, to keep high performance laptops sufficiently charged during heavy productivity usage.
Charge smartphones and other devices with USB-C downstream charging ports featuring BC 1.2 charging specification. Fast-charge ports support always-on charging so devices will charge whether or not a host laptop is connected.
Integrated 6-Port USB Hub & SD Card Reader
This USB-C Gen 2 docking station features 6 downstream USB ports in total to connect USB peripherals and an SD 3.0 UHS-I card reader for media storage.
• 2x USB-C 3.2 Gen 2 - 10 Gbps (BC 1.2 Fast-Charge + Aways-On)
• 2x USB-A 3.2 Gen 1 - 5 Gbps
• 2x USB-A 2.0 - 480 Mbps
• SD 3.0 UHS-I Card Reader
Also included, is a gigabit Ethernet port with PXE Boot, as well as 4-position TRRS stereo audio for a headset and mic.
Additional Security Features
This USB-C docking station comes with plenty of security features two K-slots for a Kensington style laptop lock.
Enhance Productivity and Device Management with the StarTech.com Connectivity Tools Application
Developed to improve performance and security, StarTech.com Connectivity Tools is the only software suite on the market that works with a wide range of IT connectivity accessories. The software suite includes:
•
Advanced Windows Layout Utility : To setup and save custom windows layouts.
•
Mac Address Pass-Through Utility : To improve network security.
•
USB Event Monitoring Utility : To track and log connected USB devices
•
Wi-Fi Auto Switch Utility : Enabling users to quickly access faster network speeds via wired LAN.
For more information and to download the StarTech.com Connectivity Tools application, please visit: www.StarTech.com/Connectivity-Tools
The StarTech.com Advantage
StarTech.com USB C Dock - Triple 4K Monitor USB Type-C Docking Station - 100W Power Delivery - DP 1.4 Alt Mode & DSC, 2x DisplayPort 1.4/HDMI 2.0 - 6xUSB (2x 10Gbps) - Windows/Chrome
SKU: DK31C2DHSPDUE£113.61 ex VAT
£136.33 inc VAT
In stockPorts & interfaces Combo headphone/mic port Yes USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2 USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 2 Headphone connectivity 3.5 mm Host interface USB 3.2 Gen 2 (3.1 Gen 2) Type-C USB 2.0 ports quantity 2 Ethernet LAN (RJ-45) ports 1 HDMI ports quantity 1 HDMI version 2.0 DisplayPorts quantity 2 Headphone outputs 1 DC-in jack Yes Connectivity technology Wired USB Power Delivery Yes USB Power Delivery up to 100 W DisplayPort version 1.4 Network Networking standards IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u Ethernet LAN Yes Ethernet LAN data rates 10,100,1000 Mbit/s Ethernet LAN (RJ-45) ports 1 Copper ethernet cabling technology 10BASE-T, 100BASE-TX, 1000BASE-T Performance Maximum digital resolution 3840 x 2160 pixels Number of displays supported 3 Product colour Black, Grey Card reader integrated Yes Cable lock slot Yes LED indicators Yes Data transfer rate 10 Gbit/s Compatible memory cards MMC, SD Certification CE, FCC, RoHS HD type 4K Ultra HD Maximum refresh rate 60 Hz Technical details Product colour Black, Grey Cable lock slot Yes Data transfer rate 10 Gbit/s Harmonized System (HS) code 84733020 Products per master (outer) case 4 pc(s) Master (outer) case width 390 mm Master (outer) case length 282 mm Master (outer) case height 195 mm Storage Card reader integrated Yes Compatible memory cards MMC, SD Power Power plug type Type M Compatible power plug types EU, UK AC input voltage 100 - 240 V Software Windows operating systems supported Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 Other operating systems supported ChromeOS Mobile operating systems supported Android 10, Android 9.0, iPadOS Indication LED indicators Yes Weight & dimensions Weight 300 g Width 210 mm Depth 90 mm Height 30 mm Package weight 1.4 kg Package width 270 mm Package depth 150 mm Package height 94 mm Design Windows operating systems supported Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 Product colour Black, Grey Cable lock slot Yes LED indicators Yes Certification CE, FCC, RoHS Packaging data Package weight 1.4 kg Package width 270 mm Package depth 150 mm Package height 94 mm Packaging content Quick start guide Yes Cables included USB Type-C to USB Type-C AC adapter included Yes Certificates Certification CE, FCC, RoHS Logistics data Products per master (outer) case 4 pc(s) Master (outer) case width 390 mm Master (outer) case length 282 mm Master (outer) case height 195 mm Harmonized System (HS) code 84733020 Other features Chipset Cypress - CYPD4236, Synaptics - VMM5320BJG-R Your parcel will arrive within 5 business days (excluding weekends and public holidays) after you place your order. Items are shipped in working days only, your order may arrive anytime between 7am and 9pm. Deliveries are not made on public holidays, so you can expect your order to arrive the next working day.
Items must be returned in an unused and saleable condition within 16 days of the receipt of goods. Please read our delivery and returns policy for further information.
